Yamaha MGX16 22-Channel Digital Mixing Console
Yamaha MGX16 22-Channel Digital Mixing Console
Couldn't load pickup availability
- Genuine Products
- Haslfree Refunds
- Fast Delivery
Description
Yamaha MGX16 22-Channel Digital Mixing Console
Key Features
- Intuitive Hybrid Control: Combines a 15+1 fader configuration with a 4.3-inch color touchscreen and control knobs for fast, precise, and effortless operation.
- Studio-Quality Mic Preamps: Equipped with 8 premium MGX mic preamps, offering an impressive 86 dB gain range and ultra-low distortion for pure, natural sound reproduction.
- Flexible Connectivity & Routing: Features extensive I/O including 8 combo mic/line inputs, 4 stereo line inputs, 8 TRS outputs, and 4 headphone ports to handle diverse setups.
- Powerful USB Audio Interface: A dual USB-C design provides a 22-in/22-out MAIN interface for multitrack recording and a SUB interface for simple 2-track recording or streaming.
- Onboard Recording & Playback: Capture up to 16 tracks directly to a microSD card for reliable backup recording or playback without needing a computer.
- Integrated Bluetooth Audio: Seamlessly stream background music or audio tracks wirelessly from smartphones or tablets with the built-in Bluetooth 5.0 receiver.
- Professional Onboard DSP: A comprehensive suite of effects and processors, including EQ, compression, gates, reverb, and delay, allows for latency-free monitoring and mix polishing.
- Assistive Mixing Tools: Features like Auto Gain, Clip Safe, and Scene Recall help simplify setup, prevent distortion, and ensure consistent, high-quality mixes.
Why Yamaha MGX16 Digital Mixer Is Better
The Yamaha MGX16 represents a significant evolution from traditional analog mixers. Unlike its predecessors, it integrates a powerful digital core with a high-resolution touchscreen, dual USB audio interfaces for multitrack recording, and Bluetooth connectivity. While many mixers in its class offer basic effects, the MGX16 includes a comprehensive suite of Yamaha's renowned DSP, including advanced tools like multiband compression and amp simulators. Furthermore, smart features like Auto Gain and Clip Safe actively assist the user in achieving a clean mix, a capability not found in purely analog consoles. This fusion of analog-style control with advanced digital processing provides a far more versatile and powerful workflow for modern audio production.
Advantages
- Fast, intuitive workflow with a touchscreen and physical faders for quick adjustments during a show.
- Scene Recall allows for instant setup changes between different bands or segments.
- Onboard 16-track recording to microSD provides a reliable way to capture live performances for later mixing.
For Studio Producers & Content Creators:
- The 22-in/22-out USB interface allows for high-channel-count multitrack recording directly into a DAW.
- Premium MGX preamps ensure clean, high-fidelity recordings of vocals and instruments.
- Integrated DSP provides latency-free monitoring with effects for performers.
For Installed Sound (Houses of Worship, Auditoriums):
- Simple Mode and assistive features like Auto Gain make it easy for volunteers and non-technical staff to operate.
- Flexible routing and multiple outputs are perfect for managing main speakers, monitors, and broadcast feeds.
- Bluetooth input simplifies playback of audio from guest devices.
Best Suitable For
- Live Bands & Ensembles: Offers enough inputs and flexible monitoring for small to medium-sized groups.
- Small to Medium Venues: A powerful and compact core for clubs, cafes, and corporate event spaces.
- Houses of Worship: Easy to use for volunteers with powerful features for more experienced operators.
- Podcast & Streaming Studios: A complete production hub with multitrack recording, sound pads, and flexible routing for online content.
- Home & Project Studios: Provides high-quality preamps and an extensive audio interface for multitrack recording and production.
Why Buy From Pro Audio Brands
- Authorized Yamaha Dealer: Ensuring you receive a 100% genuine product.
- Official Yamaha India Warranty: Benefit from manufacturer-backed service and support across India.
- GST Invoice for Input Credit: We provide proper GST billing so businesses can claim tax benefits.
- Expert Technical Support: Our team of audio professionals is ready to assist with setup and troubleshooting.
- Fast, All-India Delivery: Secure and insured shipping to all major cities and towns, including Mumbai, Delhi, Bangalore, and Chennai.
- Competitive Pricing: Get the best value for your investment with our fair and transparent pricing.
FAQs - Yamaha MGX16 22-Channel Digital Mixing Console with Audio Interface
Q: Can the Yamaha MGX16 record all 22 channels multitrack to a computer?
A: Yes, the main USB-C port functions as a 22-in/22-out audio interface, allowing you to record all input channels as separate tracks into a compatible DAW on your computer.
Q: Does this mixer have motorized faders?
A: No, the MGX16 features high-quality, non-motorized faders for manual control. Scene recalls will change the digital settings, but the faders themselves will not move.
Q: Can I record directly to a USB flash drive?
A: No, direct recording is supported via the microSD card slot, not a USB flash drive. You can record up to 16 tracks simultaneously to a microSD card.
Q: What is the 'True Sound' philosophy?
A: This is Yamaha's commitment to reproducing sound as transparently and naturally as possible. In the MGX16, this is achieved through high-quality MGX preamps and AD/DA converters that ensure ultra-low distortion and a wide dynamic range.
Q: Is phantom power available for all mic inputs?
A: Yes, +48V phantom power is available for all 8 combination XLR inputs, allowing you to use condenser microphones.
Q: Can I use the built-in effects while recording via USB?
A: Yes, you can apply the onboard DSP effects to your input channels and choose to record either the 'dry' (unprocessed) signal or the 'wet' (processed) signal to your DAW.
Q: What software is included with the MGX16?
A: The mixer comes with download codes for Cubase AI, WaveLab Cast LE, the Basic FX Suite, and the Steinberg Plus software bundle.
Q: Does the Bluetooth connection support two-way audio for calls?
A: No, the Bluetooth functionality is for audio input only (A2DP), designed for playing back music or audio tracks wirelessly into the mixer.
Q: What are the 'assistive features' like Clip Safe?
A: Clip Safe is an intelligent function that automatically prevents digital clipping and distortion on your inputs if a signal level unexpectedly becomes too high, ensuring a cleaner recording.
Q: Can I control the mixer remotely with an iPad?
A: The product specifications do not mention a dedicated remote control app for the MGX16. Control is primarily through the physical interface on the console itself.
Q: What kind of power supply does it use?
A: The MGX16 uses an external AC power adapter (PA-300C), which is included in the box. This ensures stable power and minimizes noise within the mixer's chassis.
Q: Is this mixer suitable for a beginner?
A: Yes, while it has professional features, the intuitive layout, touchscreen, and 'Simple Mode' make it accessible for beginners to learn and achieve good results quickly.
Q: How do I claim the warranty in India?
A: As an authorized dealer, we facilitate the warranty process. Simply provide us with your GST invoice, and we will guide you to the nearest authorized Yamaha service center in India.
Q: Can I rack-mount the MGX16?
A: The specifications do not explicitly mention a rack-mount kit. Given its design with side panels, it is intended primarily for desktop use.
Q: What is the difference between the MAIN and SUB USB ports?
A: The MAIN USB-C port is a full 22x22 interface for multitrack recording. The SUB port is a simpler 2x2 interface, ideal for stereo playback from a secondary device or for basic streaming setups.
Specifications
| Specification | Details |
|---|---|
| Mixing Channels | 8 Mono + 4 Stereo + 1 Sound Pad + 2 FX Return |
| Inputs | 8 Mic/Line (Combo), 4 Line (TRS), 4 Line (RCA) |
| Outputs | 2 Main (XLR), 8 Omni (TRS), 4 Headphones |
| USB Audio Interface | Main: 22-in/22-out (32-bit/96kHz), Sub: 2-in/2-out (16-bit/48kHz) |
| Onboard Recording | microSD Card: 16-track record / 2-track playback (24-bit/up to 96kHz) |
| Bluetooth | Version 5.0, A2DP |
| Display | 4.3-inch color touchscreen |
| Faders | 16 x 60 mm (Non-motorized) |
| Phantom Power | +48 V (switchable per 4 channels) |
| Frequency Response | +0.0 / -0.5dB (20 Hz to 20 kHz) |
| Dimensions (W×H×D) | 420 mm x 97 mm x 321 mm (16.5" x 3.8" x 12.6") |
| Net Weight | 4.7 kg (10.4 lbs) |
| Included Software | Cubase AI, WaveLab Cast LE, Basic FX Suite, Steinberg Plus |
| In the Box | MGX16 Mixer, AC Power Adapter (PA-300C), Start Guide, Steinberg Software License Cards |
