Solid State Logic PURE DRIVE QUAD 4-Channel Preamplifier
Solid State Logic PURE DRIVE QUAD 4-Channel Preamplifier
Couldn't load pickup availability
- Genuine Products
- Haslfree Refunds
- Fast Delivery
Description
Solid State Logic PURE DRIVE QUAD 4-Channel Microphone Preamplifier with USB Audio Interface
Beyond its exceptional preamps, the PURE DRIVE QUAD functions as a high-performance 12-in / 12-out USB-C audio interface, capable of 32-bit/192 kHz conversion. This dual-purpose design makes it the heart of any professional or project studio. Each of the four channels features three distinct switchable modes: an ultra-clean, transparent 'Clean' mode; a warm, harmonically rich 'Classic Drive'; and a new, edgier 'Asymmetric Drive'. Combined with comprehensive digital connectivity including ADAT and AES/EBU, the QUAD seamlessly integrates into any recording setup, offering a complete, high-fidelity input solution.
Key Features
- Four PUREDRIVE™ Preamps:Inherited from the SSL ORIGIN console, these preamps provide exceptional clarity and up to +65 dB of clean, stepped gain.
- Three Distinct Analogue Modes:Instantly switch between Clean, Classic Drive (even harmonics), and Asymmetric Drive (odd harmonics) for unmatched tonal versatility on any source.
- Integrated USB-C Interface:Operates as a professional 12-in / 12-out, 32-bit/192kHz sound card for direct, high-resolution recording into your DAW.
- Advanced Digital Connectivity:Features ADAT, AES/EBU, and Word Clock I/O, allowing seamless expansion of and integration with existing professional audio systems.
- Dedicated Analogue Inserts:Each channel includes a balanced insert send and return for easily integrating outboard EQs, compressors, and effects before the A/D conversion.
- Auto-Sensing Hi-Z Inputs:Four front-panel instrument inputs automatically switch priority, making it effortless to record guitars, basses, and synthesizers with optimal impedance.
- Precision Channel Controls:Every channel is equipped with 48V phantom power, polarity invert, and a 3rd order high-pass filter for complete control at the input stage.
- Flexible Output Routing:Includes dedicated main monitor outputs, two independent high-power headphone outputs, and four line-level outputs for versatile monitoring and routing.
Why SSL PURE DRIVE QUAD Is Better
Where most preamplifiers or audio interfaces force a choice between transparent audio capture or a fixed analogue character, the PURE DRIVE QUAD excels by offering both—and more—on every single channel. Unlike interfaces that rely on digital emulation, the QUAD provides three distinct, purely analogue circuits: pristine Clean, vintage-style Classic Drive, and a completely new Asymmetric Drive. This provides a sonic palette previously unavailable in a single unit. Furthermore, its combination of four console-grade preamps with a professional 32-bit/192 kHz USB interface and extensive digital I/O like ADAT and AES makes it a far more comprehensive and flexible studio front-end than its competitors.
Advantages
* Capture sources with the ideal sonic character from the start, reducing reliance on post-processing plugins.
* The stepped gain controls ensure perfect stereo matching and precise session recall.
* Integrate outboard gear seamlessly using the dedicated insert points on each channel.
* Expand your existing setup via ADAT, adding four premium SSL preamps to any compatible interface.
For Recording Artists & Bands:
* Track multiple instruments and vocals simultaneously, each with a tailored analogue tone.
* The high-quality, auto-sensing Hi-Z inputs provide a superb DI for guitars and basses.
* Two independent headphone outputs allow for customized monitor mixes for multiple performers.
* The all-in-one design simplifies the recording chain, letting you focus on performance.
Best Suitable For
- Professional Studio Engineers: Because it provides four channels of premium SSL sound with unmatched tonal flexibility and digital integration, streamlining workflow.
- Home Studio Producers: Because it combines a high-end 4-channel preamp and a professional audio interface, offering a complete front-end solution in a single unit.
- Recording Bands and Ensembles: For its ability to capture multiple instruments and vocals simultaneously, each with its own distinct and dialed-in analogue character.
- Drummers and Percussionists: To capture a multi-miked drum kit with a combination of clean and driven sounds directly at the source.
Why Buy From Pro Audio Brands
- Authorised SSL Dealer: We are an official retailer for Solid State Logic in India, guaranteeing 100% genuine products and peace of mind.
- Official Manufacturer Warranty: Every unit comes with a full manufacturer's warranty, with service and support available within India.
- GST Invoice for Input Credit: We provide a proper GST invoice with every purchase, allowing you to claim input tax credit for your business.
- All-India Secured Delivery: Your investment is safe with us. We ship via trusted courier partners, fully insured, to any location in India.
- Expert Audio Consultation: Our team consists of audio professionals who can provide genuine, expert advice to help you make the right choice.
FAQs - Solid State Logic PURE DRIVE QUAD 4-Channel Preamplifier
Q: What are the three different preamp modes?
A: Clean is an ultra-low noise, transparent preamp. Classic Drive adds warmth with even-order harmonics. Asymmetric Drive adds more aggressive saturation with odd-order harmonics.
Q: Can I use the PURE DRIVE QUAD as a standalone audio interface?
A: Yes, it functions as a complete 12-in/12-out USB-C audio interface with high-quality 32-bit/192kHz converters.
Q: Is the gain control stepped or continuous?
A: The gain control is stepped, which is ideal for precise adjustments and easy recall of settings, especially when matching levels for stereo recording.
Q: Can I integrate the QUAD with my existing Universal Audio Apollo interface?
A: Absolutely. You can connect the QUAD's ADAT output to your Apollo's ADAT input to add four high-quality SSL preamps to your setup.
Q: What is the benefit of 32-bit recording?
A: 32-bit float recording provides a massive dynamic range, making it virtually impossible to digitally clip your audio during recording, offering much more flexibility in post-production.
Q: Do I need to install drivers to use it?
A: It is class-compliant on macOS. For Windows systems, an ASIO/WDM driver is required for optimal performance, which can be downloaded from the SSL website.
Q: How do the Hi-Z instrument inputs work?
A: When you plug a 1/4" TS cable into any of the four front-panel inputs, it automatically detects the connection and switches that channel's source from the rear XLR/Line input to the front Hi-Z input.
Q: Can I bypass the preamp and just use the converters?
A: Yes, you can feed a line-level signal directly into the insert return, which bypasses the preamp stage and goes directly to the A/D converter.
Q: Are the headphone outputs powerful enough for high-impedance headphones?
A: Yes, the QUAD features two independent and powerful headphone amplifiers designed to drive a wide range of headphones effectively.
Q: Is this unit rack-mountable?
A: Yes, it is a standard 2U 19-inch rackmount unit.
Q: What is included in the box?
A: The box contains the PUREDRIVE QUAD unit, a standard IEC power cable, a USB-C to C cable, a USB-C to A cable, and the user documentation.
Q: Do you provide a GST invoice for business purchases?
A: Yes, we provide a full GST-compliant invoice with every order, allowing you to claim Input Tax Credit.
Q: What is the warranty policy in India?
A: The product comes with a 1-year official SSL manufacturer warranty, fully serviceable in India through authorized channels.
Q: Can I use the USB and ADAT outputs at the same time?
A: Yes, the outputs are available simultaneously, offering great flexibility for routing audio to different devices.
Q: What is the purpose of the insert points?
A: The insert points allow you to connect external analogue hardware like compressors or EQs into the signal path before the audio is converted to digital.
