Product details

10in | 6out Audio Interface

Designed to take your recordings to the next level in every way, the iD14 (MKII) delivers professional audio performance in a compact and modern desktop package, giving you everything you need to make studio quality recordings at home.

The professional sound you deserve

Every iD interface features the Audient Console Mic Preamp, the same discrete circuit design found in our renowned recording console the ASP8024-HE. Designed to deliver ultra- low noise and low distortion with a touch of classic analogue warmth, iD14’s two Audient mic pre’s will give you the professional sound you deserve.

How does it sound?

The Audient mic pre is a high grade hybrid discrete and op amp design that delivers a clean, accurate and detailed translation of your source.

Now that’s quiet

With a noise floor 30,000 times quieter than the signal level your recordings will be captured with stunning clarity.

Class leading converters
Its all in the details

iD14’s converters make sure you hear every nuance, every detail of your audio, enabling you to take your recordings to the next level. Offering an incredible 126dB of dynamic range you will hear your audio more accurately, make better creative decisions and experience stunning clarity directly from your desktop.

Speaker Outputs
Be immersed

Connect and listen to your mixes through two sets of speakers with iD14’s four line outputs. Alternatively use the extra line outputs to send audio to an external headphone amp for distribution to your artists.

Dual Headphone Outputs
Powerful performance

Equipped with both a jack and mini jack connection and a powerful headphone amp capable of driving headphones up to 600Ohms, iD14 is ready to take on the most demanding recording sessions.

JFET Instrument Input
Plug and play

Designed to replicate the input stage of a classic valve amplifier, iD14’s harmonically rich JFET Instrument Input is the perfect sonic foundation for your guitar or bass and amp sims.

Expand via ADAT
More channels, more possibilities

Plan for the future with iD14’s digital input. Supporting both ADAT and SPDIF, iD14 gives you the option to add up to eight extra mic pre inputs letting you expand your rig and take on larger sessions.

Experience
ultra low latency

Keep it simple with the powerful but intuitive iD Mixer. Create and customise low latency headphone mixes, utilise the flexible monitor control or simply keep an eye on your levels – all from one easy to use app.

Innovation meets
communication

iD14’s dedicated talkback technology enables you to use any audio source connected to your computer such as a built in or USB microphone as your talkback mic, freeing up valuable mic pres for recording.

Work Faster

Speed up your workflow with the iD button. Assign any of iD14’s advanced monitoring features to the iD button, including DIM, CUT, Polarity Reverse, Mono Sum, Talkback or Cue Mix monitoring, and experience complete control at your fingertips.

True Phantom Power
Get the most from your mics

Designed to deliver true phantom power over USB, iD14 will make sure your mics get the power they need to ensure optimal sonic performance.

USB Bus Powered
Set up in seconds

No need to find a power outlet as iD14 is powered directly from your computer via USB, without compromising on sound quality or performance.

Creativity unleashed

Audio Loop-back enables you to capture playback from applications on your computer at the same time as your microphones. Ideal for content creators, podcasters and streamers.

Features

• 2 x Audient Console Mic Preamps
• Class Leading AD/DA Converters
• 1 x JFET Instrument Input
• 1 x ADAT Input
• 4 x Line Outputs
• 1 x Dual Headphone Output
• Speaker + Headhphone On/Off Button
• +48V Switches
• ScrollControl
• Ultra-low Latency Software Mixer (Direct Monitoring)
• Audio Loop-back
• True Phantom Power over USB
• USB3.0 Bus Powered
• 24bit/96khz
• Mac & Windows Compatible
• All Metal Design
• Free Software + Plugins

Specifications

• D.I / Instrument Input
  RANGE:40dB
  LINEUP:12dBu = 0dBFS
  THD+N @ 0dBu:0.1%
  SNR:100dBu A-Weighted
  FREQUENCY RESPONSE – MIN GAIN:±0.5dB 10Hz to 20kHz
  1/4” TS JACK:Tip (Hot) & Sleeve (Shield)
• Microphone Preamplifier
  GAIN RANGE: 58dB
  LINEUP:12dBu = 0dBFS
  MIC MAX INPUT LEVEL:12dBu
  MAX INPUT LEVEL:21dBu
  INPUT IMPEDANCE (Mic):2.8k
  INPUT IMPEDANCE (Line):>8k
  THD+N @ 0dBu:0.00170%
  THD+N @ 0dBu MAX GAIN:<0.04%
  SNR:101dBu A-Weighted
  EIN:129dB A-Weighted
  CMRR @ 1k:>75dB
  CROSSTALK:>-100dB
  FREQUENCY RESPONSE – MIN GAIN:±0.5dB 10Hz to 40kHz
  XLR COMBI FEMALE:Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
  1/4” TRS JACK:Tip (Hot), Ring (Cold) & Sleeve (Shield)
• Analogue to Digital Converter
  THD+N @ -1dBFS:0.001%
  DYNAMIC RANGE:120dB A-Weighted
  CMRR:>80dB
  FREQUENCY RESPONSE:±0.5dB 10Hz to 40kHz
• Line Outputs (DAC)
  LINEUP:12dBu = 0dBFS
  THD+N @ -1dBFS:0.0006%
  DYNAMIC RANGE:125.5dB A-Weighted
  CROSSTALK:>120dB
  FREQUENCY RESPONSE:±0.1dB 10Hz to 40kHz
  1/4” TRS JACK:Tip (Hot), Ring (Cold) & Sleeve (Shield)
• Headphone Outputs
  LINEUP:18dBu = 0dBFS
  THD+N @ -1dBFS:0.0009%
  DYNAMIC RANGE:125.5dB A-Weighted
  CROSSTALK:>116dB
  FREQUENCY RESPONSE:±0.25dB 10Hz to 40kHz
  MAXIMUM LEVEL @ 30R:2.59V Peak, 1.827V RMS, 223mW
  MAXIMUM LEVEL @ 62R:4.18V Peak, 2.95V RMS, 280mW
  MAXIMUM LEVEL @ 600R:7.72V Peak, 5.46V RMS, 100mW
  1/4” TRS JACK:Tip (Left), Ring (Right) & Sleeve (Shield)
• USB-C High Speed
  BUS POWER:
  MIN REQUIREMENT:0.9A @ 5V >=USB 3.0 Port
  MAX REQUIREMENT:1.5A @ 5V USB-C: Provides higher headphone outputs levels
  No. of INPUT CHANNELS:10
  No. of OUTPUT CHANNELS:6
  DSP MIXER LATENCY ROUND TRIP (in-to-out):44.1kHz 0.65mS
  DSP MIXER LATENCY ROUND TRIP (in-to-out):48.0kHz 0.6mS
  DSP MIXER LATENCY ROUND TRIP (in-to-out):88.2kHz 0.33mS
  DSP MIXER LATENCY ROUND TRIP (in-to-out):96.0kHz 0.31mS
