Audient EVO 8 USB Audio Interface

Product details

Capture your microphones and instruments and start recording audio directly to your computer with EVO 8’s intuitive feature set. EVO 8 has all of the innovative new features found on EVO 4 but provides additional inputs and outputs alongside unrivalled performance and functionality – all off bus power.

Made for you

Made for the smart creative, EVO 8 will deliver a powerful recording solution no matter your artform.

Capture creativity fast

Whether recording your latest track, producing a beat, or creating a podcast EVO 8’s advanced and versatile feature set lets you take control of any recording session.

Unrivalled audio performance

Building on Audient’s 20+ years of audio design experience, EVO 8 gives you unrivalled audio quality on your desktop.

4x EVO Preamps

Get the most from your microphones with the warm and accurate EVO preamps – offering 58dB of gain range.

High Performance Converters

Hear your recordings more accurately than ever and make better mix decisions with 113dB of dynamic range.

Instrument Input

Plug your guitar or bass straight in through the JFET instrument input and start recording instantly.

Smartgain Mode
Work smarter not harder

Make sure you capture everything perfectly with Smartgain mode. Start playing or singing and Smartgain mode will automatically set the level of your microphones. You can even perfectly match and adjust gain to all channels simultaneously.

SmartMuting

Connecting a set of headphones to either of the headphone ports will automatically mute the corresponding speaker outputs, making switching between loudspeaker monitoring and headphone monitoring quick and seamless.

Work anywhere

All of EVO 8’s advanced features are powered directly from your computer via USB, letting you start recording on the go, whenever inspiration strikes.

Free software

Compatible with all major audio software and plugins, EVO 8 comes bundled with a collection of professional software, giving you everything you need to start recording.

Audio Loop-back

Audio Loop-back enables you to record your computer audio at the same time as your microphones. Ideal for podcasters and streamers.

Customisable Software Mixer

Designed to simplify and adapt to your workflow, the EVO Mixer enables you to effortlessly set up and route your inputs + outputs, provide ultra-low latency monitoring, balance and set your levels, activate phantom power, set up dedicated artist headphone mixes and more.

Features

• 4 x EVO Mic Pres
  Class Leading Converters
• Smartgain
• Smart Touchpoints
• JFET Instrument Input
• 2 x Stereo Speaker Outputs
• 2 x Headphone Outputs
• Low Latency Software Mixer
• Audio Loop-back
• USB2.0 Bus Powered
• Phantom Power
• Free Software + Plugins

Specifications

• Microphone Preamplifier
  Mic Gain Range: 58dB
  Line Gain Range: 58dB (-10dB pad)
  Phantom Power: 48V +/-4V @ 10mA/Channel (only 2 channel available on USB-A host computers
  Mic EIN: <-128dBu
  CMRR: >85dB @ 1kHz
  Maximum Input Level: +16dBu
  Input Impedance (Mic): >3kΩ Balanced
  Input Impedance (Line): >10kΩ Balanced
  Frequency Response: +/-0.5dB 10Hz to 40kHz
  Crosstalk: <-105dBu @ 1kHz & 10kHz
  THD+N @ 0dBu (1kHz): <0.0015%
  SNR: 100dB
  XLR: Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
  1/4” Jack: TIP (Hot), RING (Cold) & SLEEVE (Shield)
• D.I
  D.I Gain Range: 58 dB
  Maximum Input Level: +10dBu
  Input Impedance: 1MegΩ Unbalanced
  Frequency Response: +/-0.5dB 10Hz to 20kHz
  THD+N @ 0dBu (1kHz): <0.3%
  SNR: 100dB
  1/4” Jack: TIP (Hot) & SLEEVE (Shield)
• ADC Inputs
  Digital Reference Level: 0dBFS = +8dBu
  Frequency Response: +/-0.5dB 10Hz to Fs/2
  Crosstalk: -105dBu @ 1kHz & 10kHz
  THD+N @ -1dBFS (1kHz): <0.001%
  Dynamic Range: 113dB A-weighted
• DAC Outputs
  Maximum Output Level: +11dBu
  Digital Reference Level:0dBFS = +11dBu
  Output Impedance: <100Ω Balanced
  Frequency Response: +/-0.5dB 10Hz to Fs/2
  Crosstalk: <-110dBu @ 1kHz
  THD+N @ -1dBFS (1kHz): <0.0015%
  Dynamic Range: 113dB A-weighted
  1/4” Jack: TIP (Hot), RING (Cold) & SLEEVE (Shield)
